Description
Explore the TrailMaster Blazer 200EX from our supplier catalog. Contact G&C for current availability, production year, color, assembly and delivery pricing.
TrailMaster Blazer 200EX — Model Details
| Engine Type | 4-stroke, single cylinder, air cooled |
|---|---|
| Displacement | 168.9 cc |
| Bore & Stroke | 2.4×2.28 inches |
| Max HP | 11.1 HP/8000rpm |
| Max Speed | 43 mph |
| Max Torque | 8.1 bs ft/6000rpm |
| Starting System | Electric |
| Emission | EPA certificated |
| Transmission | Automatic CTV with reverse |
| Driveline | Chain / Dual Wheel Drive |
| Front Suspension | Double A-arm |
| Rear Suspension | Swing arm |
| Front Brake | Hydraulic Disc Brakes |
| Rear Brake | Hydraulic Disc Brakes |
| Front Tire | 20×7-8 |
| Rear Tire | 22×10-10 |
| Length | 85 inches |
| Width | 53.1 inches |
| Height | 57.5 inches |
| Wheelbase | 59 inches |
| Seat Height | 13.8 inches |
| Ground Clearance | (min) 6.7 inches |
| Weight GW/NW | 573 / 485 lbs |
| Max Load | 500 lbs |
| Fuel Capacity | 2.25 gal |
Published equipment
- Fuel injection system operates under any weather and at any altitude
- Fully automatic with reverse, high performance 168.9cc GY6 engine with internal F-N-R
- Alloy wheels with 22X7-10 front and 22X10-10 rear aggressive tires
- Top LED light bar
- 4MM high quality windshield
- Nitrogen gas adjustable front and rear shock
- Upgraded racing seat belt
- Digital speedometer/odometer
- Aluminum side mirrors
- Turn signals
- Sporting steering wheel
- Stylish design
- Exciting graphics
- Five-point safety harness
- Electric start with kill switch
- Adjustable steering wheel
- Individual sports seats
- LED headlight
- Bikini sunshade top
- Adjustable driver seat: pedal to seat back adjustable from 36” to 43”
- Rack and pinion steering wheel
- Front and rear hydraulic disc brake
- 4-point rear swing arm
- Parking brake
- 4-wheel stylish fenders
- Trailer hitch
- Large rear utility rack
- Large gas tank
Choose options & request a quote
Model photos
Supplier reference photographs show model examples; pictured colors and accessories may vary. Specifications are supplier-published reference values, checked October 30, 2026. Confirm rider fit, exact production year, included equipment and final setup before purchase.
